10G SFP+ LC 1270/1330nm 40km

Description

10.3Gbps SFP+ BIDI Transceiver, Single Mode, 40km Reach TX1270nm / RX1330nm (TX1330nm / RX1270nm) are hot pluggable 3.3V Small-Form-Factor transceiver module. They are designed expressly for high-speed communication applications that require rates up to 11.3Gb/s, they are designed to be compliant with SFF-8472 SFP+ MSA. The module data link up to 40km in 9/125um single mode fiber.

Features:

lSupports up to 11.3Gbps bit rates

lHot-pluggable SFP+ footprint

l1270nm DFB laser and PIN receiver

l1330nm DFB laser and PIN receiver

lUp to 40km for SMF transmission

lCompliant with SFP+ MSA and SFF-8472 with single LC receptacle

lCompatible with RoHS

lSingle +3.3V power supply

lPower dissipation<1.0W

l2-wire interface with integrated Digital Diagnostic monitoring

lEEPROM with Serial ID Functionality

lOperating case temperature:     Standard:  0 to +70°C  Industrial: -40 to +85°C

Application

l10GBASE-BX & 10GBASE-ER/EW

l10G SONET/SDH, OTU2/2e

 STANDARD

lCompliant with SFF-8472

lCompliant to SFF-8431

Ordering information

Product Description

TX1270/RX1330,  10Gbps,  LC,  40km,    0°C~+70°C,  with DDM

TX1330/RX1270,  10Gbps,  LC,  40km,    0°C~+70°C,  with DDM

TX1270/RX1330,  10Gbps,  LC,  40km,  -40°C~+85°C,  with DDM

TX1330/RX1270,  10Gbps,  LC,  40km,  -40°C~+85°C,  with DDM
