Features:
lQSFP28 MSA compliant
lHot pluggable 38 pin electrical interface
l4 LAN-WDM lanes MUX/DEMUX design
l4x25G electrical interface
lMaximum power consumption 6.5W
lLC duplex connector
lSupports 103.125Gb/s aggregate bit rate
lUp to 80km transmission on single mode fiber
lOperating case temperature: 0℃ to 70℃
lSingle 3.3V power supply
lRoHS 2.0 compliant
|
Parameter
|
Symbol
|
Min
|
Typ
|
Max
|
Unit
|
Notes
|
|
Maximum Supply Voltage
|
Vcc
|
0
|
|
3.6
|
V
|
|
|
Storage Temperature
|
Ts
|
-40
|
|
85
|
℃
|
|
|
Relative Humidity
|
RH
|
5
|
|
85
|
%
|
1
|
|
Damage Threshold, each lane
|
THd
|
6.5
|
|
|
dBm
|
|
|
Parameter
|
Symbol
|
Min
|
Typ
|
Max
|
Unit
|
|
Supply Voltage
|
Vcc
|
3.135
|
3.3
|
3.465
|
V
|
|
Case Temperature
|
Top
|
0
|
|
70
|
℃
|
|
Link Distance with G.652
|
|
|
|
80
|
km
|
|
Parameter
|
Symbol
|
Min
|
Typ
|
Max
|
Unit
|
Note
|
|
Power dissipation
|
|
|
|
6.5
|
W
|
|
|
Supply Current
|
Icc
|
|
|
1.8759
|
A
|
Steady
state
|
|
Transmitter
|
|
Data Rate, each lane
|
|
|
25.78125
|
|
Gbps
|
|
|
Differential Voltage pk-pk
|
Vpp
|
|
|
900
|
mV
|
At 1 MHz
|
|
Common Mode Voltage
|
Vcm
|
-350
|
|
2850
|
mV
|
|
|
Transition time
|
Trise/Tfall
|
10
|
|
|
ps
|
20%~80%
|
|
Differential Termination Re-
sistance Mismatch
|
|
|
|
10
|
%
|
|
|
Eye width
|
EW15
|
0.46
|
|
|
UI
|
|
|
Eye height
|
EH15
|
95
|
|
|
mV
|
|
|
Receiver
|
|
Data Rate, each lane
|
|
|
25.78125
|
|
Gbps
|
|
|
Differential Termination Re-
sistance Mismatch
|
|
|
|
10
|
%
|
At 1 MHz
|
|
Differential output voltage
swing
|
Vout, pp
|
|
|
900
|
mV
|
|
|
Common Mode Noise, RMS
|
Vrms
|
|
|
17.5
|
mV
|
|
|
Transition time
|
Trise/Tfall
|
12
|
|
|
ps
|
20%~80%
|
|
Eye width
|
EW15
|
0.57
|
|
|
UI
|
|
|
Eye height
|
EH15
|
228
|
|
|
mV
|
|
|
Application
l100GBASE-ZR4 100G Ethernet
lTelecom Networking
Standard
lCompliant to IEEE 802.3bm
lCompliant with QSFP28 MSA
lCompliant to SFF-8636
Ordering information
|
Product
|
Specifications
|
|
Pack
|
Rate
(Gbps)
|
Tx
(nm)
|
Po
(dBm)
|
RX
|
Sen
(dBm)
|
Temp
(℃)
|
Reach
(KM)
|
DDM
|
|
100G QSFP28 Transceiver, ZR4 80km
|
QSFP28
|
100G
|
EML LWDM
|
2.0~6.5
|
SOA+PIN
|
＜-28
|
0~70
|
80
|
Y
|
|
